High Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver Magnets

Product Categories
Mianyang Henshin Magnetic Material Co., Ltd.
Contact Now

High Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver Magnets

  • 1
  • 2

Brand Name : HSMAG

Model Number : Sm2Co17

Certification : ITAF16949 ISO9001

Place of Origin : China

MOQ : 1PCS

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100000PCS 15Days

Delivery Time : 30 work days

Packaging Details : Cartons, sheet metal shielding packaging

Orientation : Thickness or according to your needs

Size : Customized Magnet Size

Material : Sintered SmCo

Grade : XG16-XG33EH

Max Working Temperature : 350℃

Tolerance : 0.05mm, 0.05mm ~ 0.1mm

Lead Time : 20 work day

Sample : Free

Contact Now

A high performance XG30 XG32 Samarium Cobalt Magnets Arc SmCo Motor Magnet
Products Description

1:5 SmCo Magnet

SmCo1:5 Magnet is also called SmCo5, the highest working can be 250℃.Based on Sm,Co and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.

2:17 SmCo Magnet

SmCo2:17 Magnet is also called Sm2Co17, the highest working can be 350℃.Based on Sm, Co, copper, iron zirconium and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.

Raw Material Ratio Energy Density ReversibleTemp.coefficient
SmCo5 Sm:Co=1:5 25MGOe - 0.05% / ℃
Sm2Co17 Sm:Co=2:17 32 MGOe - 0.03% / ℃.
Surface Method Thickness Colour
Ni Electroplate 10 Silver Semi-bright
Zn Electroplate 10 Silver Semi-bright
Ni-Cu-Ni Electroplate 10 Silver Semi-bright
Ni+Sn Electroplate

Ni 5

Sn 10

 Silver Semi-bright
Aluminum Chromate Lon-deposition 5 Yellow Semi-bright
Resin Coatings Spray Painting Electrophoresis 20 Black

High Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver MagnetsHigh Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver Magnets

Froperties of SmC0 Magnets

High Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver Magnets

Company Profile

Mianyang Hengxin Magnetic Materials Co., Ltd. was founded in 1999, specializing in the manufacture and development of sintered samarium cobalt permanent magnet materials and devices; after years of development, it has formed a production capacity of 500 tons of samarium cobalt permanent magnet materials per year, and is the main manufacturer of samarium cobalt permanent magnet materials and devices in China.

High Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver Magnets

Our Certificates

High Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver Magnets

Factory Tour

High Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver Magnets

Packaging Shipping
High Performance Samarium Cobalt Magnets XG30 XG32 Round Small Silver Magnets
